DB Drive WDX8G5.4 : 8" Dual 4-Ohm Subwoofer

Features

• 2.5" 4 layer Anodized aluminum high-temperature voice coil
• Non-pressed paper cone
• Double stitched foam surround
• Dual poly-cotton dampeners
• Die-cast aluminum vented basket
• Rubber gasket trim ring
• Large gauge compression terminals
• Protective magnet cover

Specifications:

Structure	8" (20.32cm) Woofer
Dynamic Power Handling	1800 Watts
Nominal Power Handling	900 Watts
Impedance	Dual 4Ω Voice Coil

Parameters:

Resonant Frequency (fs)	34.109Hz
D.C. Voice Coil Resistance (Re)	2 x 3.2Ω
Mechanical Quality Factor (Qms)	3.193
Electrical Quality Factor (Qes)	0.615
Total Quality Factor (Qts)	0.516
Equivalent Air Volume to Cms (Vas)	7.375 L
Mass of Diaphragm/Coil (Mms)	169.4 kg
Force Factor (Bl)	19.44
Sound Pressure Level (SPL)	78.6 dB

Product Manual

Product Manual PDF

Description

Feel the power of pure sound with the DB Drive WDX8G5.4 Subwoofer!

Unleash the full potential of your audio system with the DB Drive WDX8G5.4: an 8-inch subwoofer that redefines what it means to experience bass. Designed with a high-temperature voice coil and a non-pressed paper cone, this subwoofer delivers crisp, clear, and thunderous lows that will elevate any listening experience. Dual poly-cotton dampeners and a die-cast aluminum vented basket ensure durability and exceptional performance under the most demanding conditions. With 1800 watts of max power and a dual 4Ω voice coil, the WDX8G5.4 offers incredible power handling and versatility. Large gauge compression terminals and a protective magnet cover complete this powerhouse, making it a must-have for true audio enthusiasts. Upgrade your ride with the DB Drive WDX8G5.4 and feel the music like never before.
