DB Drive E7 3X : 3-way Crossover

Features

• Remote Bass Control Included
• Front & Rear High-Pass Crossover - 18dB/Octave, Variable Frequency 35-400Hz, 20x Multiplier Option
• Sub Low-Pass Crossover
• Double Sided PCP Board
• Three Stereo Outputs - 5Vms
• Output Level : 8 volts max
• Two Stereo Inputs with Parallel Input Option
• Frequency Response : 10Hz - 50KHz - 3dB
• THD : 0.0015%

Specifications

Supply Voltage	11-15V DC
Input Current	0.3amp max
Distortion	0.01% THD
Frequency Response	10Hz - 50KHz -3dB
S/N Ratio	>95dB
Separation	60dB

Description

Rev up your audio experience with the DB Drive E7 3X 3-Way Crossover! This powerhouse of a crossover is designed to deliver unparalleled sound quality and control, making it a must-have for any serious audio enthusiast. Featuring remote bass control, and front & rear high-pass crossover with an 18dB/octave variable frequency range of 35-400Hz, this crossover ensures that every note is crisp and clear. The sub low-pass crossover and double-sided PCP board only add to the precision and power of your audio setup. With a frequency response of 10Hz to 50KHz -3dB and a maximum output level of 8 volts, your music will reach new heights. Plus, the three stereo outputs with 5Vms and two stereo inputs with a parallel input option provide versatile connectivity options. Elevate your car audio system to the next level with the DB Drive E7 3X 3-Way Crossover – where every beat matters and quality is never compromised!
